| Model | LED (Pcs) | Wattage (W) | Colour | Lumens (Lm) | Size (mm) |
Beam Angle(°) |
Input Voltage(V) |
Waterpriif (IP) | Download |
| KG710137 | SMD | 3W | CCT Tunable | 150Lm | 45mm×65mm×45mm Cutout:37x37mm | UP+DOWN | 220-240V | IP44 |  |
| KG710237 | SMD | 6W | CCT Tunable | 300Lm | 75mm×39mm×45mm Cutout:68x37mm | UP+DOWN | 220-240V | IP44 | |
| KG710537 | SMD | 12W | CCT Tunable | 600Lm | 147mm×39mm×45mm Cutout:140x37mm | UP+DOWN | 220-240V | IP44 | |
| KG711037 | SMD | 22W | CCT Tunable | 1100Lm | 280mm×39mm×45mm Cutout:273x37mm | UP+DOWN | 220-240V | IP44 | |
| KG711537 | SMD | 35W | CCT Tunable | 1600Lm | 413mm×39mm×45mm Cutout:405x37mm | UP+DOWN | 220-240V | IP44 | |
